J2Z系列振实台主要与混砂机配用，在自硬砂造型过程中，实现砂型紧实。
主要技术参数
|
固定式振实台参数 |
|||
|
型号Model |
载重(t) Weight |
台面长x宽(mm） Table surface Length x Width |
备注 |
|
J2Z2101 |
1 |
1200x900 |
均可按照用 Can be made upon request of
|
|
J2Z2102 |
2 |
1500x1200 |
|
|
J2Z2103 |
3 |
2000x1500 |
|
|
J2Z2105 |
5 |
2500x2500 |
|
|
J2Z2106 |
6 |
2000x1200 |
|
|
J2Z2108 |
8 |
2500x1800 |
|
|
J2Z2110 |
10 |
2000x2000 |
|
|
J2Z2112 |
12 |
2500x1800 |
|
|
J2Z2115 |
15 |
3500x3000 |
|
|
J2Z2120 |
20 |
4000x4000 |
|
|
J2Z2125 |
25 |
4000x3000 |
|
|
J2Z2130 |
30 |
3000x3000 |
|
|
J2Z2140 |
40 |
5000x4000 |
|
|
J2Z2150 |
50 |
3600x3600 |
|
|
J2Z2180 |
80 |
7000x5000 |
|
|
J2Z21120 |
120 |
7000X7000 |
|
|
升降式振实台参数 |
|||
|
型号Model |
载重(t) Weight |
台面长x宽(mm） Table surface Length x Width |
备注 |
|
J2Z2201 |
1 |
900x600 |
均可按照用户要求定制 Can be made upon
|
|
J2Z2202 |
2 |
1400x800 |
|
|
J2Z2203 |
3 |
1600x800 |
|
|
J2Z2204 |
4 |
2000x800 |
|
|
J2Z2205 |
5 |
1800x800 |
|
|
J2Z2206 |
6 |
2700x1000 |
|
|
J2Z2208 |
8 |
1900x1000 |
|
|
J2Z2210 |
10 |
1800x1200 |
|
|
J2Z2215 |
15 |
2600x1400 |
|
|
J2Z2220 |
20 |
2700x1400 |
|
